JDS-298 DC 서지 발생기

DC surge generator 10.1 inch capacitive touch screen, based on Android development

측정규격: MIL-STD 1275D

목록보기

Typical application scenarios

The JDS-298 DC surge generator is a specially designed generator to simulate the 28V DC power supply characteristics of military vehicles. Surge voltage testing can be performed on vehicle equipment in accordance with standards GJB298-1987 and MIL-STD 1275D.

Key features

1. The host adopts 10.1-inch capacitive touch screen and built-in Android control system.

2. Data storage interface USB.

3. Support test parameter cruise function, open test program setting.

4. Built-in file management system, support U disk reading and writing, can easily import, export and save related programs and test reports.

5. It has the functions of EUT failure detection, power supply circuit safety interlock and emergency button reset.

6. The indication function area can display the system running status in real time.

7. Customize test settings, wide range can be set.

Main technical indicators

Model	JDS-298
Pulse voltage	0-40V(20mΩ internal resistance) 0~100V(500mΩ internal resistance)	Surge cycle	1s-99s
Ascending and descending time	≤1ms	Number of iterations	1 to 9999 order
Surge time	50ms-1000ms	Maximum output current	100A
Output impedance	20mΩ or 500mΩ	Maximum operating voltage	DC 0-40V

Direct current supply, Coupled network, Built-in diode
