HVP-2 고전압 펄스 시험기

Highly reliable test system specially designed for the characteristics and requirements of impulse voltage immunity test in electromagnetic compatibility test

목록보기

Typical application scenarios

Instruments used for testing the insulation performance of electricity meters, low-voltage electrical appliances, household appliances, component sockets and connectors and cables. The instrument is designed according to relevant standards at home and abroad, which provides a reference standard for measuring the insulation performance of electronic and electrical equipment.

Key features

1. Program-controlled boost, surge voltage up to 12kV, meet the harsh test requirements.

2. Built-in voltage and current differential probe to realize surge voltage, current peak measurement function and surge.

3. Threshold setting function.

4. Built-in file system, support U disk reading and writing, convenient for the import, export and saving of related programs and test reports.

5. It adopts 10.1-inch LCD touch screen display, and the human-computer interaction interface is friendly.

6. Equipped with RJ45 communication function.

Main technical indicators

Model	HVP-2
Peak output voltage	0.3kv-12.0kv ±10%(0.1kv/step)
Output voltage waveform	1.2/50us
Output impedance	500Ω, tolerance ±20%
Output polarity	positive, negative, or automatic alternation
Pulse interval	3s-9999s (1s/step) (0.3kv-9.9kv) 10s-9999s (1s/step) (10kv-15.0kv)
Number of pulse	1-9999 (1s/step)
Trigger mode	manual mode, automatic mode
Overcurrent alarm	0.3A-10A, allowable error: ±10% ±3 words
